530009 C32 SERIES PUMP WITH ADJUSTABLE UNLOADER 3200 PSI
In stock
Part Number
530009
Special Price
$229.90
Regular Price
$254.90
530009 AAA PROFESSIONAL triplex 3200 PSI pumps are highly efficient pumps that minimize engine load while delivering top performance.
AAA pumps are equipped with Patented Powerboost technology that provides higher pressure at the spray nozzle.
These AAA 530009 pumps contains dual oversized ball bearings for better wear, friction resistance and longer lasting performance in tough cleaning environments.
The 530009 Pressure washer Pumps are equipped with the Easy-Start feature to assist in hassle free starting under low pressure.
To distinguish which 53009 pump you have, refer to the diagrams and note which unloader your pump has.
The 530009 AAA Pump is equipped with the Easy-Start feature.
Features:
- 3200 PSI @ 2.8 GPM MAX
- PowerBoost Technology
- Fully adjustable unloader system with ergonomic control Sight glass and advanced oil seal technology, does away with the need for a dipstick
- Thermal relief protection to prevent pump overheating
- Dual oversized radial ball bearings are installed for better wear, friction resistance and precision ceramic coated pistons for extended seal life Crankcase is manufactured from fully anodized die cast aluminum for corrosion protection and is sealed to prevent contamination and lube failure
- Forged brass head
- Gas engine flange and hollow shaft that fits most horizontal shaft engines
Specifications:
- PSI: 3200 GPM:
- 2.8 Kit Includes:
- 3/4 Garden Hose Inlet Port:
- Threaded M22 Male Hose Connection
- Inlet Pressure Range: 10-60 PSI
- Thermal Relief Port: 1/4" NPT
- Shaft Diameter: 3.4"
- Flange Bolt Pattern: SAE J-609A Key Way:
- 3/16" Pump Oil Capacity: 8.0 FL oz.
- PowerBoost:
- Brass manifold head
- 7110169 Crankcase
Need Help? Call us:
1-269-685-4123Related Items
-
-
-
-
-
-
-
-
-
Outlet Fitting Assembly with Boost Valve C30, C31, C32 Series AAA Pumps
Part Number : 7106264$30.03
The burst pressure of a pressure washer pump is the highest pressure it produces when the trigger is first squeezed and does not reflect the actual operating pressure.
The true operating PSI is determined by the engine’s horsepower and the size of the nozzle being used.
It is possible for a single pump to be rated at various GPM and maximum PSI levels by adjusting factors such as engine RPMs, nozzle size, or engine horsepower.
The true operating PSI is determined by the engine’s horsepower and the size of the nozzle being used.
It is possible for a single pump to be rated at various GPM and maximum PSI levels by adjusting factors such as engine RPMs, nozzle size, or engine horsepower.
