7110110 Pressure Valve Repair Kit for OEM Technologies Pressure Washer Pumps

The 7110110 valve repair kit is designed to replace worn or damaged pressure valves in compatible OEM Technologies pressure washer pumps with aluminum pump bodies. This kit helps restore proper pressure and smooth pump operation by replacing common failure components in the intake and discharge ports.

Each kit includes six complete replacement pressure valves and is suitable for use in axial cam and triplex plunger pressure washer pumps rated at 3,700 PSI or less.

7110110 Features

• Replaces worn, stuck, or damaged check valves
• Helps correct low pressure and rough pump operation
• Includes six fully assembled replacement valves
• Designed for intake and discharge port applications
• Suitable for axial cam and triplex plunger pumps

7110110 Specifications

• Part Type: Pressure Valve Repair Kit
• Valve Quantity: 6 complete pressure valves
• Pump Compatibility: Aluminum body OEM Technologies pumps
• Maximum Pressure Rating: 3,700 PSI or less
• Valve Material: Stainless steel and plastic

• Metal base with O-ring diameter: 11.880 mm
• Spring cage diameter: 11.420 mm
• Base to spring cage length: 13.990 mm
• Spring cage projection diameter: 6.550 mm
• Spring cage projection length: 3.052 mm
• Total valve length: 16.898 mm

Service Note

When installing the 7110110 valve repair kit, all components of the old pressure valves must be completely removed, including the valve cage and spring. Failure to remove all old components may result in damage to the newly installed valves.

*Additional compatibility may exist for other brands and models manufactured using the same pressure valve design. Always verify compatibility by confirming your unit’s model number and part diagram.
