9.6GA12 Triplex Plunger Pump 9.6GA12 AAA by FNA 2.8GPM 3200PSI

9.6GA12 AAA™ PROFESSIONAL triplex pumps are highly efficient pumps that minimize engine load while delivering top performance.

AAA™ pumps are equipped with Patented Powerboost™ technology that provides higher pressure at the spray nozzle.

The 9.6GA12 AAA Pump contains dual oversized ball bearings for better wear, friction resistance and longer lasting performance in tough cleaning environments.

The 9.6GA12 AAA Pump is equipped with the Easy-Start feature.

Features:

3200 PSI @ 2.8 GPM
PowerBoost™ Technology
Fully adjustable unloader system with ergonomic control
Sight glass and advanced oil seal technology, does away with the need for a dipstick
Thermal relief protection to prevent pump overheating
Dual oversized radial ball bearings are installed for better wear, friction resistance and precision ceramic coated pistons for extended seal life
Crankcase is manufactured from fully anodized die cast aluminum for corrosion protection and is sealed to prevent contamination and lube failure
Forged brass head
Gas engine flange and hollow shaft that fits most horizontal shaft engines

Specifications:

PSI: 3200
GPM: 2.8

Inlet Port: 3/4? GH
Discharge Port: Threaded M22 male connection
Inlet Pressure Range: 10-60 PSI
Thermal Relief Port: 1/4" NPT
Shaft Diameter: 3.4"
Flange Bolt Pattern: SAE J-609A
Key Way: 3/16"
Pump Oil Capacity: 8.0 FL oz.
PowerBoost®: Yes
Head: Brass
Model: 9.6GA12
