DW3635 Pump, Horizontal Triplex Plunger 3600 psi 3.5 gpm by AAA

The DW3635 AAA Pump Kit is an Original Equipment brand new direct drive horizontal triplex plunger pump rated at 3.5 GPM and 3600 Max PSI when running 3400 RPM to deliver top cleaning performance.

Made in Italy and Engineered to surpass expectations the DW3635 from FNA Group can be used on many different pressure washers under multiple brands including Simpson, DeWalt, Stanley, Black and Decker, Excel, Mi-T-M, Cub Cadet, John Deere, Briggs and Stratton, Troy-Bilt, Craftsman, and other power washer brands.

This AAA DW3635 Pump Features:

• 3600 PSI+ @ 3.5 GPM Max PSI with rated HP Gas Engine
• Fully adjustable unloader system with ergonomic control
• Easy Read Sight glass and advanced oil seal technology, does away with the need for a dipstick
• Thermal relief protection to prevent pump overheating
• Oversized radial ball bearings are installed for better wear and friction resistance, and precision ceramic coated pistons for extended seal life
• Crankcase is manufactured from fully anodized die-cast aluminum for corrosion protection and is sealed to prevent contamination and lube failure
• Gas engine flange and hollow shaft that fits most horizontal 1 Inch shaft engines

DW3635 Triplex Plunger Pump Specifications:

• Condition: Brand New
• PSI: 3600 Max Burst
• GPM: 3.5
• Inlet Port: 3/4" GH
• Discharge Port: 3/8" Quick connect female
• Inlet Pressure Range: 10-60 PSI
• Thermal Relief Port: 1/4" NPT
• Shaft Diameter: 1" Inch
• Flange Bolt Pattern: Standard SAE Multi-Point
• Seals High-performance double seal system prevents water leaks.
• Pump Oil Capacity: 10 fl oz.
• Head: Forged Brass
• Country of Origin: Italy
