WMI924 H.F Ignitor Ignition Transformer for Portable Heaters 120 Volt
In stock
Part Number
WMI924
$34.29
The WMI924 Ignitor Assembly is the H.F Ignitor Model Series WMI924 120 Volt ignition module with insulated secondary spark plug leads used to create continuous ignition for combustion to occur during operation.
These H.F. Ignitor WMI924 ignition devices are used to produce a continuous spark for portable kerosene heaters made for Dayton, Master, Heat Hog, Remington, Black and Decker, Stanley, and other multiple brands of portable construction heaters.
This WMI924 Ignitor Assembly is one of several different ignition devices used for portable kerosene heaters made for Dayton, Master, Heat Hog, Remington, Black and Decker, Stanley, and multiple other brands of portable construction heaters.
The Model WMI924 Ignitor has the following specifications.
Model Number WMI924 H.F. IgnitorPrimary Voltage AC 120Volts 50/60Hz
Primary Leads: 18 inch 2 pin connector with Blue and Red leads
Secondary Voltage 16.5 KV o-p
Secondary Leads: 24-inch Black High Temperature spark plug leads.
Made in Korea
CROSS REFERENCE PART NUMBERS:
GHP Dyna-Glo Part Numbers
39E0-0005-00, 39E0-0006-00, 39E0-0007-00, 39E0-0008-00, 39E0-0009-00, 39E0-0014-00, 39E0-0021-00, 39E0-0025-00, 39E0-0029-00, 39E0-0070-00, 39E0-0071-00
World Marketing Dura Heat part Numbers
21-1045, 21-1046, 21-1047, 21-1501, 21-2024, 21-4004, 21-6004
Pinnacle Products Part Numbers:
70-037-0100, 70-037-0300, 70-037-0400, 70-037-0500, 70-025-0200, 70-025-0300
