W010-1866 Napoleon SIT Liquid Propane Gas Pilot Assembly

The W010-1866 is a liquid propane gas pilot assembly from SIT Controls. This pilot assembly features an IPI electronic ignition and is designed to fit direct vent fireplaces from Napoleon.

The assembly may also fit other direct vent propane fireplaces. Always refer to the owner's manual for your direct vent LPG fireplace to confirm compatibility.

Components of the W010-1866 LPG Pilot

A flame sensor, intermittent spark ignition, pilot tube, two-way pilot hood, and thermocouple make up the W010-1866 pilot assembly. The W010-1866 also features a vertical 3 in. mounting bracket.

• 3 in. top-Mount bracket with air flow hole located below the bracket
• 2-Way flame pilot hood
• Spark electrode and cable.
• Sensing electrode and cable.
• Ø1/8 in. in. diameter aluminum pilot tube, 24 in. long
