VFPC20IN73N-1 Natural Gas Empire Fireplace Insert with Electronic Ignition - 20,000 BTUs

VFPC20IN73N-1 is a vent-free natural gas fireplace insert from Empire Comfort Systems with an electronic ignition and intermittent pilot. The VFPC20IN73N-1 should only be operated with natural gas. Using liquid propane or any other fuel type could lead to accidental damage to the unit.

Vent-free units do not require any air intake or exhaust output vents to the outside. However, they do have specific air flow and clearance requirements that should be paid carful attention during installation. Refer to the VFPC20IN73N-1's user manual for further information.

The intermittent pilot in this Empire fireplace insert is only lit when required for ignition, as oppose to a standing always-on pilot light. On/Off pilot control is also part of this fireplace insert, along with a battery-operated ignitor and natural gas regulator.

A list of manufacturer-approved replacement parts and accessories can be found in the owner's manual.

Specifications

Gas Type: Natural Gas

Max. BTU Input: 20,000 BTU/hr.

Min. BTU Input: 14,000 BTU/hr.

Orifice Size: 2.1mm

Air Shutter Type: ¹/₈ in. Open

Min/Max Gas Pressure: 4.5 in. / 10.5 in. WC

Insert Width: 29 ¹/₄ in.

Insert Height: 19 ¹/₈ in.

Insert Depth: 13 ⁹/₁₆ in.
