H7271 Electric Proflame Liquid Propane Gas Valve

The H7271 is a Proflame gas valve that is designed for use with liquid propane gas heating appliances that use an electronic intermittent pilot ignition.

H7271 services liquid propane heating appliances from brands such as Lennox, IHP, and Superior, among others.

The H7271 gas valve is a Proflame 885 series valve that has an integrated automatic HI/LO adjustable stepper motor.

Specifications for the H7271 Gas Valve

Gas Type: Liquid Propane Gas

Max. Capacity: 97,000 BTU/Hr. @ 1 in. w.c pressure drop

Pressure Setting Range: 10 in. w.c to 6.4 in. w.c

Maximum Inlet Pressure: 1/2 PSIG

Ambient Operating Temperature: 32° - 175°F

Valve Connection for Pilot: 7/16 UNS x 1/4 in.

Inlet Valve: 3/8 in. NPT

Outlet Valve: 3/8 in. NPT

Electrical Information

Voltage: 5.25 V DC

Amps: 0.0145 A

Valve Coil Resistance: 362 Ω ± 10% @ 68°F

Motor Coil Resistance: 24 Ω ± 10% @ 68°F
