UVC36 Majestic 36 in. Vent Free Room Heater with Piezo Ignitor

The UVC36 is a Majestic vent free heater that features millivolt gas control with a Hi/Lo adjustment knob. No outside vent system is required for the UVC36.

This Majestic heater has a max input rating of 25,000 BTU/Hr. It features a Piezo ignitor and supports a blower fan assembly.

Information on Model Number Variants

The UVC36 is a variant of the UVC series of fireplaces. This unit has a glass front panel. For units that feature a screen panel, please see the UVS36 listing.

Depending on the initial gas type, the model number for the UVC36 may change.

• Natural Gas Model: UVC36RN
• Liquid Propane Gas Model: UVC36RP

Specifications of the UVC36RN

Gas Type: Natural Gas

Max. Input Rating: 25,000 BTU/Hr.

Min. Input Rating: 17,500 BTU/Hr.

Min. Inlet Pressure: 5.5 in. w.c

Max. Inlet Pressure: 14.0 in. w.c

Manifold Pressure: 3.5 in. w.c

Dimensions

Height: ~34 1/4 in.

Width: ~36 in.

Depth: ~3 1/4 in.

Specifications of the UVC36RP

Gas Type: Liquid Propane Gas

Max. Input Rating: 25,000 BTU/Hr.

Min. Input Rating: 18,750 BTU/Hr.

Min. Inlet Pressure: 11.0 in. w.c

Max. Inlet Pressure: 14.0 in. w.c

Manifold Pressure: 10 in. w.c

Dimensions

Height: ~34 1/4 in.

Width: ~36 in.

Depth: ~3 1/4 in.
