AF-1110S Solenoid Valve American Flame

AF-1110S is the 6 Volt solenoid valve for the American Flame AF-1110S Series gas valve.

AF1110S also works as a replacement for ProCom part number OD-C0889-11

AF-1110S Replacement Instructions:

Remove batteries from receiver:

Disconnect Red and Black wires from the AF1110S Solenoid at connections coming from Receiver Box:

Remove the E-Clip on the top of the stem that holds the old solenoid on the valve.

Slide the old solenoid off from the stem and slide the new AF-1110S solenoid valve back on in the same directions as the one you took off.
Note: This would be the smooth side facing up away from the gas valve.

Install the E-Clip back on the stem and make sure the clip is securely in the grove.

Reconnect wires in the same order and to the same color as they were removed.
