5140117-70 Pressure Switch 4 Port 110-135 No Unloader Special

The 5140117-70 Pressure Switch is a 4-port pressure switch that is fixed at 110 PSI cut-in and 135 PSI cut-out pressures with no unloader for pressure relief when the air compressor turns off.

This Black and Decker, ON/Off pressure switch, has special connections for the molded cord and only has one set of spade contacts inside the switch.

This 51401117-70 switch is the OEM replacement made by Furnas Hubble for use on air compressors by DeWalt, DeVilbiss, Sears Craftsman, Porter Cable, and others.

The Pressure Switch is used to control the operation of the air compressor.

This senses the pressure in the compressor tank and turns the compressor on and off to maintain the desired pressure.

This switch has four ports: One for the supply line, one for the outlet line, and the other two ports for the safety valve and pressure gauge.

The following are the specifications of the 5140117-70 pressure switch.

• Pressure Range:110 Cut-In to 135 PSI Cut-Out

• Number of Ports: Four 1/4 Female FPT

• Unloader: No

• OEM Part: Yes

• Made is USA

• Used on Air Compressors By: Stanley Black and Decker Brands

The 5140117-70 Pressure Switch was used on the following models of oil-free air compressors.

CPFAC2040P-CA Porter Cable Oil-Free UMC Compressors Type 0,1,2,3
CPFAC2040P  Porter Cable Oil Free UMC Compressor

3JR70-CA Oil Free UMC Compressor

IRFA153-CA Oil Free 1.5HP 3 Gallon UMC Compressor Types 0,2,3,4

HFAC153 Oil Free 1.5HP 3 Gallon UMC Compressor Type, 0,1,2,3,4
