80078 Chant Liquid Propane Pressure Regulator RTZ-11 9/16 UNF Outlet

The 80078 Regulator is a Chant replacement pressure regulator LPG liquid propane manufactured by Chant for Enerco, HeatStar, Mr. Heater and various other brands of vent free heaters.

80078 Regulator Specifications:

Brand: Chant

Series: 219529

Model: RTZ-11-15A-LPG

Inlet PSI: 1/2 PSIG

Outlet: 10" W.C. LPG

Inlet Thread Size: 3/8 NPT

Inlet Port Diameter Ø 5/8 in.

Outlet Thread Size: 9/16 UNF

Outlet Port Diameter: Ø 1/2 in.

Service Note

The RTZ-11-15A-LPG is a series of regulators that include multiple different thread pitch outlets.

The 80078 regulator has a 9/16" UNF outlet port

Verify the thread pitch to your old regulator as the 80078 is one of several RTZ-11-15A-LPG labeled regulators.
