7110264 OUTLET FITTING PHOENIX 28 SERIES PUMPS

The 7110264 Outlet Connector fitting for OEM Phoenix 28 series pumps is a 22MM outlet fitting with O-Ring that is used on the following FNA Group models:

• 520004 Horizontal Axial Cam Pressure Washer Pump
• 520006 Horizontal Axial Cam Pressure Washer Pump
• 510020 Vertical Axial Pump
• 510021 Vertical Axial Pump
• 51AL19 Vertical Axial Pump
• 51AL24 Vertical Axial Pump

Note
Please verify this is the correct outlet fitting for your pump with the listed sizes below.

The 7110264 is installed is removed using an 8MM Allen Wrench

The 7110264 Outlet Connector has the following dimensions:

• 22.00MM Outside Diameter Threads for the Hose Thread Connection.
• 19.85MM Outside Diameter Threads going into the pump.
• 14.00MM Inside Diameter for Hose connection.
