ODS-0003 Pilot Assembly Natural Gas ODS Sensor with Thermopile for Real Frye burners
In stock
Part Number
ODS-0003
$125.00
The ODS-0003 Pilot Assembly is the Natural Gas RH Peterson Oxygen Depletion Sensor Pilot Assembly use with vent free Real Frye burners only.
This RH Peterson Pilot Assembly has the following specifications:
This RH Peterson Pilot Assembly has the following specifications:
Pilot Assembly ODS Oxygen Depletion Sensor parts are all integrated to provide long life and guaranteed performance.
- Single long-life 32 Inch thermocouple wire.
- Protected flame inside the pilot burner to help protect against influences by air currents.
- Built in Injector at approximately 166 W energy consumption.
- 750 mV Thermopile with 24 Inch wire.
- Complies with current European and CSA Norms.
- Suitable for all Natural Gas Grades.
- Fail Safe Oxygen Depletion System
- 3/8 24 UNF 2Ao5 mm Gas Connection.
- M8 x 1 Thermocouple connection nut.
