NG82-M8-24-TP Pilot ODS Assembly with Thermopile for Natural Gas

The NG82-M8-24-TP is our Allparts Basic aftermarket OEM equivalent replacement Natural Gas Pilot ODS Assembly engineered for high-quality and is rated for 5000 plus hours of operation with a 1 year replacement warranty.

The Pilot ODS Oxygen Depletion System ODS assembly with integrated thermocouple and thermopile for appliances burning Natural Gas, including Unvented, Vent-Free, and Direct Vent fireplaces, gas logs, stoves, heaters, pedestal stoves, and other similar appliances using Natural Gas for combustion.

The NG82-M8-24-TP  Pilot ODS assembly parts are all integrated to provide long life and guaranteed performance.

Single 900MM long-life thermocouple wire.

Protected flame inside the pilot burner to help protect against influences by air currents.

Built in Injector at approximately 166 W energy consumption.

750 MV Thermopile with Support and 24MM Leads

Suitable for use Natural Gas only.

Fail Safe Oxygen Depletion System

3/8 24 UNF 2Ao5 mm Gas Connection.

M8 x 1 Thermocouple connection nut.

This Natural Gas Pilot ODS can be used as a replacement for most natural Gas Pilot ODS with Thermopiles used in many of the Empire, Monessen, Majestic, Vanguard, Vermont Castings, Desa International, Vanguard and other fireplaces and gas logs from many different manufacturers.

All appliance repairs should be made by a qualified certified HVAC technician with proper testing equipment.
