LPG8413 PILOT ODS ASSEMBLY PROPANE LPG

The LPG8413 Pilot assembly is a Liquid Propane Gas OEM replacement Pilot ODS Assembly that is rated for 5000 + hours of operation.

This OEM Sit Controls replacement Pilot ODS can be used on many of the HHT, Hearth and Home Technologies, Vermont Castings, Vanguard, Comfort Glow, Desa, FMI, Design Dynamic, Monessen, Empire, Majestic, Martin, and other fireplaces, pedestal stoves and gas logs from many different manufacturers.



The LPG8413 Pilot ODS Oxygen Depletion System (ODS) assembly with integrated thermocouple and thermopile for appliances burning LPG Gas / Propane, including Unvented, Vent-Free, and Direct Vent fireplaces, gas logs, stoves, heaters, pedestal stoves and other similar appliances using Liquid Propane Gas for combustion.

The LPG8413 Pilot ODS / Oxyprotector parts are all integrated to provide long life and guaranteed performance.

• Single long life thermocouple wire.
• Protected flame inside the pilot burner to help protect against influences by air currents.
• 0.22 Built in Injector at approximately 166 W energy consumption.
• Thermopile Support.
• M4 Mounting bracket tabs.
• Complies with current European and CSA Norms.
• Suitable for all Propane Grades.
• Fail Safe Oxygen Depletion System
• 3/8" 24 UNF 2Ao5 mm Gas Connection.

• M8 x 1 Thermocouple connection nut.
