LPG84-M8-24-TP Pilot ODS Assembly with Thermopile for Liquid Propane Gas

The LPG84-M8-24-TP is an Allparts Basic OEM equivalent aftermarket replacement LPG Liquid propane Gas Pilot ODS Assembly and is rated for 5000 plus hours of operation.

The Pilot ODS Oxygen Depletion System ODS assembly with integrated thermocouple and thermopile for appliances burning LPG Propane Gas including Unvented, Vent-Free and Direct Vent fireplaces, gas logs, stoves, heaters, pedestal stoves and other similar appliances using Propane Gas for combustion.

The LPG84-M8-24-TP  Pilot ODS assembly parts are all integrated to provide long life and guaranteed performance.

Single 900MM long life thermocouple wire.

Protected flame inside the pilot burner to help protect against influences by air currents.

0.38 Built in Injector at approximately 166 W energy consumption.

750 MV Thermopile with Support and 24MM Leads

Suitable for use LPG Propane Gas only.

Fail Safe Oxygen Depletion System

3/8 24 UNF 2Ao5 mm Gas Connection.

M8 x 1 Thermocouple connection nut.

This Propane Gas Pilot ODS can be used as a replacement for most Propane Gas Pilot ODS with Thermopiles used in many of the Empire, Monessen, Majestic, Vanguard, Vermont Castings, Desa International, Vanguard and other fireplaces and gas logs from many different manufacturers.
