7154 High Pressure Fuel Pump Single Stage Clockwise Rotation for Kerosene and Diesel Fuel Units
The SUNTEC A1TD-7154 Fuel Pump is a Single Stage High-Pressure Pump with a clockwise rotation and will fit the Master B350 and B600 portable heaters.
Service Note:
The A1YD-7154 Fuel pump is designed for Diesel Fuel #1and #2 (blends no greater than 5%)
The A1YD-7154-B Fuel pump is designed for Fuel oil #2 and lighter, B6-B100 (blends from 6% up to 100% biodiesel, per ASTM D396)
One pipe installation:
The by-pass plug must not be installed.
The excess fuel is returned back to the inlet.
Two pipe installation :
The steel plug of the return port must be removed, and the by-pass plug must be inserted in the return port, allowing excess fuel to be bypassed back to the tank.
The return plug must not be reinstalled.
Bleed: In one pipe operation, the easy flow bleeder valve must be loosened to bleed the system.
Bleeding in two-pipe operation is automatic, but it may be accelerated by loosening the easy flow bleeder.
Suntec A1YD-7154 Specifications:
OEM Suntec
OEM #A1YD-7154
Condition: New OEM Original
Returnable: No
Color Black
Depth Inches: 4 11/20
Height Inches: 4 3/5
Limited Warranty: 1 Year
Model: A-7000 Series
Nozzle Capacity At Rated Psi GPH 3-7
Pump Type: Single Stage Two Pipe Usage
Rated Pressure: Psi 100 Max 150 Adjustable
4 GPH 100 PSI For # 2 and Lighter Fuels
3 GPH 110-150 PSI For # 2 up to B5 Fuels
Rotation And Nozzle Location: LH-RH
Shaft Speed 1725 RPM
Weight Lbs.: 7.0
Width Inches:3-5/8
A1YD-7154
LH Rotation, RH Nozzle Location as viewed from shaft end, 1725 RPM, 7GPH/3psi, 100/150 Rated Pressure
Specifications:
A - Single Stage
1 - 1725 RPM
Y - 7 GPH
D - L.H. Rotation - R.H. Nozzle
71 - Hub 54 mm, Lip Seal
54 - Mounting Style and Specialty Pumps
