H8562 886 PROFLAME GAS VALVE SIT PROFLAME NATURAL GAS
In stock
Part Number
H8562
$191.00
The H8562 is a Proflame 886 series Natural Gas valve for IHP and Lennox gas stoves, fireplaces, and inserts.
Verify model number of your valve before ordering.
Sit 880 Proflame Series
HI/LO burner adjustment with manually operated knob
Verify model number of your valve before ordering.
This H8562 Gas Valve is for Natural Gas only with the following specifications:
Sit 880 Proflame Series
HI/LO burner adjustment with manually operated knob
Drop-out current Greater than 125mA with coil resistance 0.018± 0.003
Gas type Natural Gas Manual Pressure set-point 3.5” w.c. ± 0.3
Gas type Natural Gas Manual Pressure set-point 3.5” w.c. ± 0.3
Range of adjustment 3.5” w.c. -1.6” w.c. Set at 30K btu/hr
Natural Gas Inlet 3/8 in. NPT
Natural Gas Outlet 3/8 in. NPT
Maximum natural gas inlet pressure 1/2 PSIG Ambient operating
temperature 32° to 175° F
Maximum @ 1 in. w.c. pressure drop 100,000 BTU per hour Regulation capacity 5,000 to 195,000 BTU AP per hour
