FK12 Manual Blower Kit for Majestic and Vermont Castings
Out Of Stock
Part Number
FK12
$149.94
The FK12 is a complete blower assembly from Allparts Equipment. This blower kit is designed for use in fireplaces from Majestic, Vermont Castings, CFM and Northern Flame.
This kit is for a manual blower assembly, which means the blower lacks an automatic thermostat and requires a dedicated wall switch to operate.
The FK12 blower fan kit is covered by a 2-year warranty from the manufacturer.
The FK12 is a complete blower kit that includes the following components:
- Blower
- Ball Bearing Motor
- 3-Prong Grounded Power Cord - 3 ft.
- Mounting Velcro with noise reduction padding
- Cross Support Brace for Chassis
Features of the FK12 Blower Fan Kit
- Padded mounts prevent the blower from rattling against the fireplace interior
- Aluminum housing keeps blower, motor, and bearing secure
- Assembly comes wired for easy installation
- Helps heat large rooms by evenly distributing fireplace heat
- Insulated motor is rated for temperatures up to 392°F
- Ball Bearings included in motor are lubricated for high-heat use
- 2-year warranty from the manufacturer
Specifications and Measurements of the FK12 Blower Kit
Assembly Length: 12.5 in.
Assembly Width: 3.73 in.
Assembly Height: 3.23 in.
Air Flow Requirements: 9.57 in. X 1.38 in.
Blower Output: 4,800 BTUs (160 CFM)
Thermostat Temperature Range: 90° - 120° F
Blower Voltage: 115V
Watts: 35
Amperage: 0.30
Motor RPM: 3000
Rotation: CW
Motor Frequency: 60Hz
The FK12 blower kit is known to fit the following partial list of gas fireplaces:
Majestic / Vermont Castings
- 33XDV, 36XDV, 39XDV
- 360DVS
- 36CFDV
- 33BDVR, 36BDVR, 39BDVR, 43BDVR
- 33BDVT, 36BDVT, 39BDVT, 43BDVT
- 33LDVR, 36LDVR, 39LDVR, 43LDVR
- 33LDVT, 36LDVT, 39LDVT, 43LDVT
- 36CDVX
- 36CDVZ
- BC36, BC36i, BC42, BC42i
- BHDR36, BHDT36
- DBR33, DBR36, DBR39
- DBT33, DBT36, DBT39
- 300DVB, 400DVB, 500DVB, 600DVB
- 300DVBH, 400DVBH
- DVR33, DVR36, DVR39
- DVBR36, DVBR42
- DVRT36, DVRT39, DVRT41, DVRT43
- DVT36, DVT39, DVT43, DVTS2
- LHEC20, LHEC30, LHECDV20, LHECDV30
- NV360, NV580, NVBC36, NVBC42, NVC36, NVC39, NVC43
- RHE25, RHE32, RHE42, RHEDV25, RHEDV32, RHEDV42
- UVC33, UVC36, UVC43
- UVS33, UVS36, UVS43
- UVSRC36, UVSRC42
- UVBC33, UVBC42, UVDC36, UVDC42
Note: The FK12 is compatible with a wide range of fireplaces, so long as there's enough clearance and air flow for the blower to operate properly. The FK12 also requires a dedicated wall switch.
