5140097-77 FIXED CHEMICAL INJECTOR FOR DEWALT PRESSURE WASHER
In stock
Part Number
5140097-77
$41.38
5140097-77 Fixed Chemical injector for DeWalt pressure washers with Cat Blue pumps.
5140097-77 Specifications:
Flow...................................3.0GPM
Nozzle Orifice....................2.1MM
Hose Barb.........................1/4"
Inlet Port............................M18 x 1.0
Discharge Port..................3/8" NPTM
Weight...............................5.3oz
Dimensions.......................2x1x1.75"
The 5140097-77 injector can be found on the following DeWalt pressure washers:
DXPW3025
DXPW60603
DXPW60604-CA
DXPW3025-CA
DXPW60604
DH3028
DH3028-CA
DXPW60603-CA
Service Note:
The optimum performance of a chemical injector occurs with a 35 ft. high-pressure hose and a minimum of 3/8 in. I.D.
The type of hose, extended lengths, reduced I.D., and fittings may create back pressures in excess of the low-pressure nozzle rating and prevent the injector from drawing chemicals.
