F1832 880 Proflame Electronic Gas Valve LP Gas - Only fits Lennox IHP

In stock

Part Number

F1832

$109.90

Part Number: F1832

Shipping Weight: 10 Lbs

Non Returnable

I understand this item CAN NOT be returned if the tamper evident packaging has been opened. Packaging is see-through to allow for proper inspection prior to unwrapping.

⇧ Check The Box If You Want To Proceed.

Qty

The F1832 Gas Valve is a Proflame 880 Series Electronic Propane Gas valve for Lennox, IHP, Superior and other brands of gas stoves, fireplaces, and inserts.

Please verify the code of your current of your valve before ordering.

This F1832 Gas Valve is for Propane Gas only with the following specifications:

Sit 880 Proflame Series
Fixed Pressure Modulator

Drop-out current Greater than 125mA with coil resistance 0.018± 0.003
Gas type L.P Gas Only- Propane
Manual Pressure set-point 10” w.c. ± 0.3

Propane Gas Inlet 3/8 in. NPT

Propane Gas Outlet 3/8 in. NPT

Maximum LP Propane inlet pressure 1/2 PSIG Ambient operating

temperature 32° to 175° F

Maximum @ 1 in. w.c. pressure drop 100,000 BTU per hour Regulation capacity 5,000 to 195,000 BTU AP per hour
