DVAG8N Direct Vent 8,000 BTU Natural Gas Wall-Mounted Heater

The DVAG8N is a vented natural gas wall heater from Ashley Hearth Products. This direct vent wall heater mounts to an exterior wall, providing a space-efficient source of heat.

This natural gas heater features an adjustable vent assembly that can fit walls from 4 1/2 in. to 10 in. thick. The venting allows for any combustion results to be sent outside, maintaining a clean air heat output.

Note: The DVAG8N is configured for use with natural gas (NG.) A qualified installer should be the only one to install this unit to ensure proper operation. Always refer to the Owner's Instructions for important information such as clearance space requirements.

Features of the DVAG8N Direct Vent Natural Gas Wall Heater

• Included hardware allows for easy wall mounting.
• Vent assembly is adjustable, allowing it to fit walls between 4 1/2 in. and 10 in. thick.
• Comes equip with a quick-starting piezo-electric ignitor.
• No room air is used for heating for a clean heat output.
• Wall mounting provides an efficient space-saving heating solution.
• Perfect for heating interior rooms up to 280 sq. ft. in size.
• Top-mounted HI/LO/PILOT control knob allows for easy heat adjustment

Specifications

Heat Rating: 8,000 BTU

Fuel Type: Natural Gas

Max Heat Coverage: 280 sq. ft.

Max. Gas Inlet Pressure: 10.5 in. W.C

Min. Gas Inlet Pressure: 5.0 in. W.C

Pressure Regulator Setting: 5.0 in. W.C

Dimensions:

Height: 20 in.

Width: 13.6 in.

Depth: 6.6 in.

Weight: 38 lbs.
