DH2260J Synetek Controls Inc Ignition Control Module

The DH2260J is an ignition control module from Synetek Controls. This control module is compatible with many ignition systems manufactured by various manufacturers and sold under a wide range of brand names.

Electrical Specifications

Electrical Rating: 24VAC +10 / -15%, 60Hz, 0.35A

Main Valve: 24VACm 1.0A Max

Proving Current: 3.1A

Inducer: 10.0A

Temperature Range: -40° to 175°F

Number of Ignition Trials: 3

Ignition Trial Duration: 4 seconds

Number of Allowed Flame Losses: 5

See associated photo for Pin Description.
