5140181-32 DeWalt Pressure Washer Pump Assembly

5140181-32 is a highly efficient AAA™ Triplex Plunger Pump that minimizes engine load while delivering top performance for various DeWalt pressure washer including the DeWalt DXPW3425 pressure washers.

The 5140181-32 Service Pump Features:

3400 PSI @ 2.5 GPM
PowerBoost Technology
Fully adjustable unloader system with ergonomic control
Sight glass and advanced oil seal technology, does away with the need for a dipstick
Thermal relief protection to prevent pump overheating
Dual oversized radial ball bearings are installed for better wear, friction resistance and precision ceramic coated pistons for extended seal life
Crankcase is manufactured from fully anodized die cast aluminum for corrosion protection and is sealed to prevent contamination and lube failure
Gas engine flange and hollow shaft that fits most horizontal shaft engines


Specifications:

PSI: 3400
GPM: 2.5
Inlet Port: 3/4" GH
Discharge Port: Threaded male fitting
Inlet Pressure Range: 10-60 PSI
Thermal Relief Port: 1/4" NPT
Shaft Diameter: 3/4"
Flange Bolt Pattern: SAE J-609A
Key Way: 3/16"
Pump Oil Capacity: 8.0 fluid ounces.
PowerBoost® Technology
Head: Brass
