VVC36N FMI DIRECT-VENT FIREPLACE SYSTEM

VVC36N is a 36-inch natural gas direct-vent fireplace manufactured by FMI Products.

Features:

• The venting system may be routed to the
outside of your home in several ways. It
may vent through the roof (vertical) or it
may vent to an outside/exterior wall (horizontal).
The vent pipe installation is very
important to allow for proper operation.
You must follow the venting instructions
very carefully for either vertical or horizontal
applications.

• This fireplace may be installed in any room
of your house provided all local codes and
these installation instructions are followed.

• This fireplace requires a wall switch, handheld
remote or wall thermostat (millivolt) for
operation (see Accessories, page 42).

• This fireplace does not require electricity
to operate.

• Only the blower requires electricity if installed
and if you plan to install the blower at
a later date, do not forget to wire the outlet at
the bottom of the fireplace when framing.

• A piezo ignitor and ceramic electrode create
spark to ignite the pilot light. It does not
require any matches, batteries or any other
sources of ignition to light the pilot.

• Each time you turn on your fireplace, you
may notice some amount of condensation
on the inside of the fireplace glass. This
is normal and will disappear after 10-20
minutes of operation.

• Your direct-vent gas fireplace system
(fireplace and venting) is a balanced and
sealed gas operating unit. It requires approximately
10-20 minutes of operating
time before the flame pattern stabilizes.

• Fireplaces with the suffix of -HA have been
designed to operate at altitudes of 4000
feet and above.
