A1YD-7154-B SUNTEC High Pressure Fuel Pump Single Stage Clockwise Rotation 1725 RPM
In stock
Part Number
A1YD-7154-B
$248.90
The SUNTEC A1YD-7154-B High Pressure Fuel Pump is a single-stage high-pressure pump with a 1725 RPM clockwise rotation used in multiple burner applications, including portable heating products, hot water pressure washers, Wayne burners, and other outdoor power equipment applications.
Service Note
Do Not use Teflon Tape during installation!
The use of Teflon tape will void the Suntec pump warranty any thread sealing compound ingested into the pump during installation can cause premature failure of the new Suntec pump.
Do not overlap sealing compound past the threads.
Suntec A1YD-7154-BSpecifications:
OEM Suntec
OEM #A1YD-7154-B
Condition: New OEM Original
Returnable: No
Color Black
Depth Inches: 4 11/20
Height Inches: 4 3/5
Limited Warranty: 1 Year
Model: A-7000 Series
Nozzle Capacity At Rated Psi GPH 3-7
Pump Type: Single Stage Two Pipe Usage
Rated Pressure: Psi 100 Max 150 Adjustable
4 GPH 100 PSI For # 2 and Lighter Fuels
3 GPH 110-150 PSI For # 2 up to B5 Fuels
Rotation And Nozzle Location: LH-RH
Shaft Speed 1725 RPM
Weight Lbs.: 7.0
Width Inches:3-5/8
For Proper Installation follow the listed instructions.
• Use 37 o JIC flare fittings.
• Use a non-hardening thread sealing compound.
• Prefill (prime) the pump on long runs to reduce dry running time.
• Check all unused pump fittings for tightness.
• Bleed system. Open bleed port approximately one turn.
Bleed for 15 seconds after clear oil begins flowing out of port.
Close bleeder valve tightly
• See page IV-1 if pump fails to prime or deliver
It is suggested that you DO NOT do the following:
• Install by-pass plug. (Will damage seal.)
• Use compression fittings. (Will eventually leak.)
• Use Teflon tape. (Will void warranty.)
• Use check valves. (Especially on gravity feed systems.) See Thermal Expansion, page III- 12.
• Exceed 10 psi (manufacturer) or 3 psi (NFPA) inlet line pressure.
• Exceed 6" hg. running vacuum (for Suntec “A” and “B” fuel units) or 2" hg. running vacuum (for Suntec “J” and “H” fuel units).
The new A1YD-7154-B Replaces the following models:
M50065 , 7154 , 1M112C-8MT2 , 098560-01 , 098560 01 , 09856001 , 98560-01 , 98560 01 , 9856001, 109930-01, 10993001
The A1YD-7154-B Fuel Pump is the newest series gear type fuel pump attached to the end of the electric motor and can deliver up to max 150 psi of fuel pump pressure.
This replaces the DESA M50065 Fuel Pump was used on many of the Desa High Pressure Oil Fired heaters and sold under various private labels including Desa International, Master Heaters, Dayton High Pressure Heaters, Sears Commercial Heaters, Reddy Heaters and others.
Some of the Model using the A1YD-7154-B / M50065 Fuel Pump are as follows:
Reddy High Pressure Heater Models: R350 , R350A , R600, R600A
Desa: B350HA , B600HA , SB350D , SB600D
Master High Pressure Heater Models: B350 , B350A , B350B , B350D , B600 , B600A , B600B , B600D
Knipce and Koehring High Pressure Heater Models: F350 , F350AP , K350 , K350A , K600 , K600A
Dayton High Pressure Oil-Fired heaters Model: 3E358 , 3E359 , 3E358A , 3E359A , 3E358B , 3E359B
L.B. White: CP350AK , CP600AK
Koehring Heaters: K350 , K350A , K600 , K600A
This replaces the DESA M50065 Fuel Pump was used on many of the Desa High Pressure Oil Fired heaters and sold under various private labels including Desa International, Master Heaters, Dayton High Pressure Heaters, Sears Commercial Heaters, Reddy Heaters and others.
Some of the Model using the A1YD-7154-B / M50065 Fuel Pump are as follows:
Reddy High Pressure Heater Models: R350 , R350A , R600, R600A
Desa: B350HA , B600HA , SB350D , SB600D
Master High Pressure Heater Models: B350 , B350A , B350B , B350D , B600 , B600A , B600B , B600D
Knipce and Koehring High Pressure Heater Models: F350 , F350AP , K350 , K350A , K600 , K600A
Dayton High Pressure Oil-Fired heaters Model: 3E358 , 3E359 , 3E358A , 3E359A , 3E358B , 3E359B
L.B. White: CP350AK , CP600AK
Koehring Heaters: K350 , K350A , K600 , K600A
Write Your Own Review
One pipe installation:
The by-pass plug must not be installed.
The excess fuel is returned back to the inlet.
Two pipe installation :
The steel plug of the return port must be removed, and the by-pass plug must be inserted in the return port, allowing excess fuel to be bypassed back to the tank.
The return plug must not be reinstalled.
Bleed : In one pipe operation, the easy flow bleeder valve must be loosened to bleed the system.
Bleeding in two pipe operation is automatic, but it may be accelerated by loosening the easy flow bleeder.
The by-pass plug must not be installed.
The excess fuel is returned back to the inlet.
Two pipe installation :
The steel plug of the return port must be removed, and the by-pass plug must be inserted in the return port, allowing excess fuel to be bypassed back to the tank.
The return plug must not be reinstalled.
Bleed : In one pipe operation, the easy flow bleeder valve must be loosened to bleed the system.
Bleeding in two pipe operation is automatic, but it may be accelerated by loosening the easy flow bleeder.
