936DV Direct Vent Natural Gas Wall-Mounted Furnace, 36,000 BTUs

The 936DV is a Kozy Heat direct vent 36,000 BTU wall furnace that comes from the manufacturer configured for use with natural gas only.

A liquid propane gas conversion kit is available and typically comes standard with the furnace. Gas conversions should only ever be done by a licensed and qualified installer.

The 936DC is designed for use with a direct venting setup, which pulls in outdoor air for combustion and pushes exhaust out.

This Kozy Heat wall furnace uses a millivolt pilot with a temperature control switch and adjustable blower fan control. It also features a Piezo spark ignitor that requires no electricity to light.

Specifications of the 936DV

Natural Gas

Heat Input Rating: 36,000 BTUs

Min. Inlet Gas Pressure: 7.0 in. W.C

Max. Inlet Gas Pressure: 10.5 in. W.C

Manifold Pressure: 3.5 in. W.C - 1.7 in. W.C

Efficiency Rating: 74%

Liquid Propane Gas

Heat Input Rating: 35,000 BTUs

Min. Inlet Gas Pressure: 11.0 in. W.C

Max. Inlet Gas Pressure: 13.0 in. W.C

Manifold Pressure: 10 in. W.C - 6.5 in. W.C

Efficiency Rating: 73%

Furnace Dimensions

Height: 32 in.

Front Width: 36 in.

Back Width: 26 in.

Depth: 18 1/4 in.
