932DV Direct Vent Natural Gas Wall Furnace, 26,000 BTUs

The 932DV is a direct vent wall furnace that is rated at 26,000 BTUs.

This Kozy Heat 932DV wall furnace comes from the manufacturer configured for natural gas, though a liquid propane gas conversion kit is available and typically comes standard with the furnace.

Gas conversions should only ever be done by a licensed and qualified installer.

A horizontal direct vent setup should always be used with the 932DV. This furnace uses outdoor air for both combustion and for venting exhaust outdoors.

The 932DV features a millivolt pilot with a temperature control switch and adjustable blower fan control. 932DV also features a piezo-spark ignitor that can light the unit even during power outages.

Specifications of the 932DV

Natural Gas

Heat Input Rating: 26,000 BTUs

Min. Inlet Gas Pressure: 7.0 in. W.C

Max. Inlet Gas Pressure: 10.5 in. W.C

Manifold Pressure: 3.5 in. W.C - 1.7 in. W.C

Efficiency Rating: 71.2%

Liquid Propane Gas

Heat Input Rating: 26,000 BTUs

Min. Inlet Gas Pressure: 11.0 in. W.C

Max. Inlet Gas Pressure: 13.0 in. W.C

Manifold Pressure: 10 in. W.C - 6.5 in. W.C

Efficiency Rating: 73%

Furnace Dimensions

Height: 25 in.

Front Width: 32 in.

Back Width: 22 in.

Depth: 18 1/4 in.
