84118218000 Pilot ODS Vent Free Fireplaces and Stoves

The 8411.8218.000 is a Sit Controls pilot assembly with an ODS. This pilot assembly is for use with natural gas fireplaces only.

This 84118218000 pilot Assembly is made by SIT Controls and was used by many manufacturers of vent-free heating products throughout North America.

The SIT Controls part number NG8218 is on the outside corner of the silver bracket between the white electrode and the corner, as shown in the picture on our site.

Features of the 84118218000 Pilot Assembly

• Single long-life thermocouple wire.
• Protected flame inside the pilot burner to help protect against influences by air currents.
• 0.22 Built-in Injector at approximately 166 W energy consumption.
• Thermopile Support.
• Complies with current European and CSA Norms.
• Suitable for all Propane Grades.
• Fail Safe Oxygen Depletion System
• 3/8" 24 UNF 2Ao5 mm Gas Connection.|
• M8 x 1 Thermocouple connection nut.

Note: This Pilot ODS Assembly should only be ordered if this is the exact replacement part for your heater, as listed in your owner’s manual. All appliance repairs should be made by a qualified certified HVAC technician with proper testing equipment.
