780-715U Ignition Control Assembly
In stock
Part Number
780-715U
$149.22
The 780-715U is a Robertshaw ignition control assembly that features flame rectification with solid-state logic and flame sensing to provide automatic sequencing. Solid-state logic and flame sending help ensure the proper operation of a connected pilot.
This control assembly is designed to work with continuous ignition pilots, as the 780-715U is able to monitor pilot burner flame to ensure steady heat. Should the pilot flame fail during the heating cycle, the control will shut off the main valve until the pilot flame is established.
In ten second increments, the 780-715U will attempt to spark the pilot. If the pilot flame is not sensed after three attempts, the control goes into a one-hour safety lockout period.
Features and Benefits
- Easy-to-install with complete in-depth installation instructions
- Pilot and main valves draw 1 Amp at 0.5 power factor
- Combined load at 1.5 Amps at 0.4 power factor
- 95% relative humidity noncondensing at 104°F
Current Specifications:
- Input voltage: 24VAC with 20VA minimum
- Ambient temperature rating: -40°F to +175°F
- Spark rate: 3 to 4 sparks/second
- Prepurge Period: None
- Maximum current load: 1.5A
- Heat Anticipator: .7 AMP
- Height: 1 1/2 in.
- Width: 4 1/8 in.
- Length: 3 in.
The Robertshaw 780-715U Ignition Control is known to replace the following direct spark ignition modules.
SP715 ROBERTSHAW
SP715 ROBERTSHAW
SP715A ROBERTSHAW
SP715A ROBERTSHAW
SP715U ROBERTSHAW
SP715U ROBERTSHAW
100-821-01 ROBERTSHAW
100-821-01 ROBERTSHAW
100-00821-02 ROBERTSHAW
S8610A1009 HONEYWELL
S8610F1008 HONEYWELL
S8610F1016 HONEYWELL
57P40 LENNOX INDUSTRIES
00018-03930 INTERNATIONAL CARBON
0384-015 INTERCOLE AUTOMATION
05-02-00244 INLAND MFG.CO.
100-00801-01 INDEECO
100-00808-01 HUPP TYPHOON A/C
100-00808-02 HUNTER MFG CO
100-00808-03 HUMMER MFG CO
100-00808-06 HOWARD
100-00808-11 HOTSY CO(THE)
100-00821-01 FEDDERS
100-801-01 INDEECO
100-808-01 HUPP TYPHOON A/C
100-808-02 HUNTER MFG CO
100-808-03 HUMMER MFG CO
100-808-06 HOWARD
100-808-11 HOTSY CO(THE)
100-821-01 ROBERTSHAW
100-821-01 ROBERTSHAW
100-821-02 FAWN ENGINEERING
1100-225 CRAIG SYSTEMS
13130417-01 COROX
150140-05-01 CONTROLS OF AMERICA
1501402601 INTERNATIONAL FREZZE
1781901 JULIETTE
1803931 JOHNSON GAS APPL.
2874 LERN INC.
32028 LARKIN COILS
32043 LARCO MFG.
35736-00 CLIMATE CONTROL
36524B001 CLEVELAND CONTROLS
36524B001S CLEAVER BROOKS
4E398 WESTWARD
50D50-843 WHITE-RODGERS
511330231 INTERNATIONAL OIL BR
5H71913B CECILWARE/COMMODORE
600963 KERONITE
62-21747-01 CARY CO. INC
62-21747-02 CARTER HOFFMAN
63534 UNI-LINE
661401 UNKNOWN
78070 LAB EQUIPMENT
780-715U UNI-LINE
780-71E C.E.T. / FRANCE
8900-657H BLANCHARD-NESS
92406 KRUGER
B1370720 BERNZ-O-MATIC
E087105 BARKOW MFG. CO.
H350IGN BARBEQUE KING
H8900657H BALYON LTD
L37-297 JOHNSTONE SUPPLY
P28740 AMERICAN INSTRUMENT
RLY1010 AMERICAN BURNER CORP
S03-00403 AMANA
SP715Z ALKO SCIENTIFIC
USI 715U A.R.A. MFG. CO.
WG37X0023 A.O. SMITH
