7211-370 PILOT ASSEMBLY 3 WAY FLAME NATURAL GAS HEARTSTONE

The 7211-370 Pilot assembly is a Natural Gas pilot containing the top-convertible pilot bracket with a preinstalled pilot orifice. It was used on the Hearthstone Direct Vent Fireplaces.

This 7211-370 pilot comes assembled with the Thermocouple, Thermo-generator, Electrode with Cable, and Pilot Tube with fixing nut.

The 7211-370 Natural Gas Tri Directional pilot assembly with the following specifications:

Includes:

• 7211-009 Pilot Gas Tube
• 7211-470 Thermocouple
• 7210-090 Thermopile with metal-wrapped leads
• 7211-430 Ceramic Electrode w/ Wire
• 7211-390 3-way Pilot Hood
• 7211-163 0.62mm NG Pilot Orifice



Service Note:

To use this pilot for an LPG, propane gas application, the 7211-136 # 35 Pilot Orifice must be ordered and installed in the field by a certified gas installer.

This 7211-370 Pilot Assembly was used for both direct vent fireplaces, stoves and gas logs, including the following models:

Hearthstone Gas Stoves:
Tuscon - Model 8700
Tribute - Model 8050
Champlain - Model 8301
STOWE - Model 8324
STOWE - Model 8321
Santa Fe Direct vent Series

This pilot fits multiple fireplace models, logs sets, and gas stoves. Please check your owner's manual and verify part numbers before ordering.
