7113376 Check Valve Kit

The 7113376 is a Simpson check valve kit. This kit contains six check valves and six O-rings and services compatible AAA and Simpson pressure washer pumps.

Dimensions of the 7113376 Check Valve Kit

Metal Base Diameter: 0.47 in. (11.89 mm.)

Top Spring Cage: 0.45 in. (11.43 mm.)

Metal Base to Spring Cage Length: 0.55 in. (13.97 mm.)

Diameter of Small Spring Cage Projection: 0.250 in. (13.97 mm.)

Spring Cage Projection Length: 0.120 in. (3.048 mm.)

Valve Length: 0.67 in. (16.89 mm.)
