7110123 SEAL RETAINER KIT C30 SERIES PUMP SET OF 3

The 7110123 is a seal retainer kit for a AAA C30 series pressure washer pump.

This 7110123 Kit contains the following:

3 - Plastic Seal Retainer Spacers
3 - Brass retainers for the 8.7GA12 Series AAA pumps
3 - O-ring Buna Metric N70 preinstalled in the brass retainers

The following measurements are approximate measurements:

3 Plastic Seal Retainer Spacers
10.60mm Total Height
12.60mm Inside Diameter
22.95mm Outside Diameter at the shoulder

3 Brass Retainer
8.90mm Total Height
12.15 Inside Diameter
26.05 Outside Diameter at the shoulder
