7106573 PUMP REPLACEMENT 3400 PSI 2.5 GPM

The 7106573 Pump is a AAA Professional triplex 3400 PSI pump that is highly efficient in minimizing engine load while delivering top performance on Simpson, DeWalt, Black and Decker, Cub Cadet, and other portable power washers.

These C30 Series AAA pumps come equipped with Patented Powerboost technology, providing higher pressure at the spray nozzle and improved performance.

All AAA C30 Series replacement pumps contain dual oversized ball bearings for better wear, friction resistance, and longer-lasting performance in demanding cleaning environments and are equipped with the Easy-Start feature to assist in hassle-free starting under low pressure.

The 7106573 AAA Pump has the following features:

Features:

• 3400 PSI @ 2.5 GPM MAX

• PowerBoost Technology

• A fully adjustable unloader system with ergonomic control Sight glass, and advanced oil seal technology eliminates the need for a dipstick.

• Thermal relief protection to prevent pump overheating

• High Quality dual oversized radial ball bearings for longer life including better wear and friction resistance.

• Precision ceramic coated pistons for extended seal life

• Crankcase is manufactured from fully anodized die-cast aluminum for corrosion protection and is sealed to prevent contamination and lube failure.

• Forged brass head

• Gas engine flange and hollow shaft that fits most horizontal shaft engines

Specifications:

• PSI: 3400 GPM:

• 2.5 Kit Includes:

• 3/4 Garden Hose Inlet Port:

• Threaded M22 Male Hose Connection

• Inlet Pressure Range: 10-60 PSI

• Thermal Relief Port: 1/4" NPT

• Shaft Diameter: 3.4"

• Flange Bolt Pattern: SAE J-609A Key Way:

• 3/16" Pump Oil Capacity: 8.0 FL oz.

• PowerBoost: Technology

• Brass manifold head
