7101225 FLOW-SWITCH ST-6 4500PSI 3/8x3/8M

In stock

Part Number

7101225

$88.05

The 7101225 Flow Switch is the ST-6 Flow Switch used on the FNA Group portable and stationary hot water pressure washers from SIMPSON.

This flow switch opens and closes electrical continuity to shut off or start machines depending on the flow—or lack of flow—of water in a high-pressure system.

This device uses a spring-assisted floating magnet to connect brass reeds to open and close the electrical circuit.

This SIMPSON 7101225 flow switch can be mounted vertically or horizontally and placed further downstream in a water system than traditional vacuum switches.

Specifications:

Maximum Pressure Range: 350 Bar - 5070 PSI
Maximum Temperature: 80° Celsius - 176° Fahrenheit
Maximum Flow Rate: 1 GPM
Minimum Flow Rate: 8 GPM
Inlet: 3/8" MPT
Outlet: 3/8" MPT
47 Inch Cord
Model: ST-6
