70-037-0500 Ignitor Ignition Module For Portable Heaters

70-037-0500 Ignitor Assembly is an H.F Ignitor Model Series WMI924 ignition module with insulated secondary spark plug leads.

The 70-037-0400 Ignitor Assembly ignition device was used for portable kerosene heaters made for Dayton, Master, Heat Hog, Remington, Black and Decker, Stanley, and other multiple brands of portable construction heaters.

The 70-037-0400 Current Ignitor Assembly is a Model WMI924 with the following specifications.

Model Number WMI924 H.F. Ignitor
Primary Voltage AC 120Volts 50/60Hz
Primary Leads: 19 inch 2 pin slip connector with Blue and Red leads
Secondary Voltage 16.5 KV o-p
Secondary Leads: 2 24-inch Black High-Temperature spark plug leads.

Made in Korea
