6003S-NG Dexen Natural Gas Vent-Free Millivolt Valve - Fixed Flame Height Muti-Port 8MM TC

The Dexen 6003S Gas valve is an Vent Free OEM CSA-certified and tested replacement millivolt-operated gas valve configured for use with Natural gas

This OEM replacement gas valve has the following specifications.


Models: 6003 NAT Description: Dexen Gas valve mV valve with quick drop-out safety magnet Gas Type: NG Pressure Setting Range Fixed: 3.5” w.c Natural Gas Range of regulation: 5,000 – 70,000 Btu/hr Ambient Temperature Range: -40°F to 175°F Control Type: On/Off Millivolt Manual Adjustment Valve Inlet Size: 3/8” & ½” NPT Outlet Size: 3/8” & ½ NPT Side Taps: 3/8” & ½” NPT Pilot: 7/16”-24 UNS

Mounting Holes: 3/16”-24 UNS

Mounting Position: Any Thermocouple Inlet: 8MM Thermopile Connections: Screw and Tab Adjustable pilot flow Pneumatically inline
