6003H-LP Dexen Propane Gas Millivolt Valve -Fixed Flame Height Thermostatically Controlled Muti-Port Universal Fit

The Dexen 6003H Propane Gas valve is an OEM CSA-certified and tested replacement thermostatically fixed flame gas valve configured for use with natural gas.

The Dexen 6003H LP has OEM replacement gas valve has the following specifications.


Models: 6003H LP Description: Dexen Millivolt Gas valve with quick drop-out safety magnet. Gas Type: LPG propane Thermostat: Built-In capillary thermostat Pressure Setting Range Fixed: 10.0” w.c Propane gas Range of regulation: 5,000 – 70,000 Btu/hr Ambient Temperature Range: -40°F to 175°F Control Type: On/Off/Thermostat Millivolt Fixed Flame Valve Inlet Size: 3/8” & ½” NPT Outlet Size: 3/8” & ½ NPT Side Taps: 3/8” & ½” NPT Pilot: 7/16”-24 UNS

Mounting Holes: 3/16”-24 UNS

Mounting Position: Any connections: Straight through or 90 Degree connections Adjustable pilot flow Pneumatically inline
