6003-LP Dexen Propane Gas Millivolt Valve - Fixed Flame Height Muti-Port Universal Fit

The Dexen 6003 LP Gas valve is an OEM CSA-certified and tested replacement millivolt-operated thermopile only gas valve configured for use with propane gas.

This OEM replacement gas valve has the following specifications.


Models: 6003 LP Description: Dexen Gas valve mV valve with quick drop-out safety magnet Gas Type: LPG Pressure Setting Range Fixed: 10.0” w.c Propane gas Range of regulation: 5,000 – 70,000 Btu/hr Ambient Temperature Range: -40°F to 175°F Control Type: On/Off Millivolt Manual Adjustment Valve Inlet Size: 3/8” & ½” NPT Outlet Size: 3/8” & ½ NPT Side Taps: 3/8” & ½” NPT Pilot: 7/16”-24 UNS

Mounting Holes: 3/16”-24 UNS

Mounting Position: Any For Use with Thermopile Only Adjustable pilot flow Pneumatically inline

Cross reference:
Robertshaw 710-502 LP
Robert Shaw RS710-502 LP
