60020 Draft Induction Motor "CAB" for Mr Heater HSU MHU Series Units

The 60020 Draft induced motor or Combustion Air Blower "CAB" is the OEM replacement draft induction motor for various compact unit heaters and compact overhead garage heaters manufactured by Enerco and sold under several brands, including Mr. Heater, Heatstar, Bix Maxx, Buddy heaters, as well as many others.

The 60020 Draft Induction motor is a 120 Volt 3000 RPM Motor with an attached fan and induction housing and was the main replacement motor used on the following partial list of heater model numbers and other privately labels units by Enerco as well as other models of compact unit heaters.

The 60020 Induced Draft Motor replaces the following Broad-Ocean Motor Company models:

• YJR-0H2
• H17-01:
• YJR-018H2/H117-01

Specifications of the 60020 Motor

• RPM: 3000 2P:
• V: 120 Hz: 60
• A: 0.85 HP: 1/40
• Class: B Motor

Dimensions of the 60020 Board Oceans Motor:

• Total Part Height: 5 ¹/₂ in.
• Top Fan Diameter: 3 in.
• Outlet Diameter: 2 ¹/₈ in.
• Outlet to Base Length: 2 ¹/₈ in.
• Base Diameter: 4 ¹/₂ in.
• Base Height: 2 in.
• Base Depth: 8 ¹/₂ in.
• Connecting Wire Length: 30 in.
• Front Screw Holes Diameter: Ø 3 ¹/₂ mm.

Service Note:

Always check the set screw on the Blower Motor Fan Collar before reassembly. We suggest Loctite 272 be used to secure the set screw.

Shipping Note:

In order to help prevent shipping damage to this product, these items are shipped in a 14x10x10 box with Expandable Foam Packaging, and dimensional weight is used to calculate shipping weights; this item is calculated at 11 Lbs, for shipping purposes.

For this reason, we needed to increase the list price of the 60020 Blower to offset the cost of the foam packaging making sure customers receive a quality, undamaged replacement motor.
