53ALD24 PHOENIX CY SERIES HORIZONTAL TRIPLEX PUMP 3400 PSI

530017 CY Series AAA™ Horizontal Triplex Plunger Pump Kit is a highly efficient pump that minimizes engine load while delivering top performance.

This AAA 530017 53ALD24 Triplex Plunger Pump is equipped with a patented Powerboost™ technology that provides higher pressure at the spray nozzle.

The 530017 contains dual oversized ball bearings for better wear, friction resistance and longer lasting performance in tough cleaning environments.

Features:
3400 PSI @ 2.5 GPM PowerBoost™ Technology
Preset Unloader system.
Advanced oil seal technology, does away with the need for a dipstick
Thermal relief protection to prevent pump overheating 140 Degree preset
Dual oversized radial ball bearings are installed for better wear and longer pump life.
Friction resistance and precision ceramic coated pistons for extended seal life Crankcase is manufactured from fully anodized die cast aluminum for corrosion protection and is sealed to prevent contamination and lube failure.
Gas engine flange and hollow shaft that fits most horizontal shaft engines.


Specifications:

PSI: 3400 GPM:
2.5 Inlet Port: 3/4" Garden Hose Connector
Discharge Port: Threaded 22MM Male fitting Inlet
Pressure Range: 10-60 PSI
Thermal Relief Port: 1/4"
NPT Shaft Diameter: 3/4"
Flange Bolt Pattern: SAE J-609A
Key Way: 3/16"
Pump Oil Capacity: 8.0 fl oz.
PowerBoost®: Yes
Head: Original was Aluminum but replacement pump is Brass.
Crankcase: 7110120
