530036 C4 Series Triplex Plunger Belt Drive Pressure Washer Pump
In stock
Part Number
530036
$533.52
The 530036 Pump is a AAA professional belt-drive commercial plunger pressure washer pump, part of AAA’s C4X series of high-quality commercial and industrial pumps.
This C4 Series AAA pump is engineered to surpass industry expectations. The 530036 professional triplex pump is highly efficient and rated up to 4400 PSI at 4.0 GPM.
AAA pumps carry a 5-year limited commercial warranty against material and workmanship defects.
Features Of The 530036 Pump:
- High-pressure pump rated for 4400 PSI @ 4.0 GPM
- Crankcase manufactured from fully anodized die-cast aluminum for protection against corrosion, sealed to prevent contamination and lube failure.
- Dual oversized radial ball bearings are installed for better wear, friction resistance, and precision polished stainless steel pistons for extended seal life
- 24mm Keyed belt Drive Shaft
- Corrosion-protected aluminum crankcase reduces wear and tear from regular use
- No dipstick is required thanks to the sight glass and advanced oil seals.
Specifications Of The 530036:
Maximum Pressure Rating: 4400 PSI
Flow Rate: 4.0 GPM
Inlet Port: 1/2” NPT
Discharge Port: 1/2” NPT
Inlet Pressure Range: 10-60 PSI
Thermal Relief Port: 1/2” NPT
Shaft Diameter: 24mm
Key Way: M8
Pump Oil Capacity: 12 fl. oz.
Head: Brass
