5140206-95 DeWalt AAA Pump Kit - 3800 PSI @ 3.5 GPM

5140206-95 is a Triplex plunger pump kit that's designed as an OEM replacement for several DeWalt pressure washers.

This 5140206-95 Replacement Triplex Plunger Pump has patented Powerboost technology with a max 3800 PSI at a flow rate of 3.5 GPM. The 5140206-95 provides higher pressure at the spray nozzle and contains dual oversized ball bearings for better wear and friction resistance.

A stainless steel fully adjustable unloader comes integrated into the pump, featuring an easy-start system.

Features

• PowerBoost™ Technology
• Fully adjustable unloader system with ergonomic control
• Sight glass and advanced oil seal technology for easy oil level management
• Thermal relief protection to prevent pump overheating
• Dual over-sized radial ball bearings for better wear, friction resistance and precision
• Ceramic coated pistons extend seal life.
• Fully anodized aluminum crankcase is sealed to prevent contamination and lube failure.
• Gas engine flange and hollow shaft that fits most horizontal shaft engines

Specifications

Pressure Rating: 3800 PSI @ 3.5 GPM Flow Rate

Kit Includes: Siphon tube with filter, mounting bolts, and shaft key

Inlet Port: 3/4” GH

Discharge Port: 3/8” Quick connect female

Inlet Pressure Range: 10-60 PSI

Thermal Relief Port: 1/2” NPT

Shaft Diameter: 24mm

Key Way: M8

Pump Oil Capacity: 11 fl. oz.

Head: Brass
