430010 Pressure Washer Pump AAA 4000 Max Boost PSI - 3.5 GPM
In stock
Part Number
430010
$289.90
The 430010 Pump is an AAA Triplex Plunger Pump is a highly efficient pump that minimizes engine load while delivering top performance.
The 430010 C42 Triplex Plunger Pump is equipped with Power Boost technology, which provides up to 4000 psi boost pressure at the spray nozzle and extends pump and engine life.
This 430010 contains dual oversized ball bearings for better wear, friction resistance, and longer-lasting performance in challenging cleaning environments.
Features:
- 4000 PSI @ 3.5 GPM
- PowerBoost Technology
- Ergonomic control and a fully adjustable unloader system
- Sight glass and advanced oil seal technology does away with the need for a dipstick
- Thermal relief protects the pump from overheating
- Dual oversized radial ball bearings are installed for better wear, and friction resistance, and precision ceramic coated pistons for extended seal life
- Crankcase is sealed to prevent contamination and lube failure from entirely manufactured anodized die-cast aluminum for corrosion protection.
- Gas engine flange and hollow shaft that fits most horizontal shaft engines
Specifications:
- PSI: 4000
- GPM: 3.5
- Kit Includes: Siphon tube with filter, mounting bolts, and shaft key
- Inlet Port: 3/4" GH
- Discharge Port: 3/8" Quick connect female
- Inlet Pressure Range: 10-60 PSI
- Thermal Relief Port: 1/2” NPT
- Shaft Diameter: 1 Inch Hollow 1/4 Keyed
- Key Way: 1/4
- Pump Oil Capacity: 11 fl oz.
- PowerBoost: Yes
- Head: Brass
Service Note:The "Burst Pressure" of a pressure washer pump is the highest pressure the pump produces when in a static position and when the trigger is first squeezed, giving the initial burst of pressure and does not reflect the actual operating pressure.
The accurate operating PSI of any pump would be determined by the engine’s horsepower and the size of the nozzle being used at the end of the wand, restricting water flow and causing back pressure.
It is possible for a single pump to be rated at various GPM and maximum PSI levels by adjusting factors such as engine RPMs, nozzle size, or engine horsepower.
