16396 High-Pressure Trigger Gun for Pressure Washers

The 16396 is a high-performance pressure washer spray gun able to handle pressures up to 3700 PSI.

This spray gun is widely utilized in both commercial and residential pressure washers that are currently manufactured and distributed throughout North America.

Features of the 16396 Spray Gun

• Includes a built-in 14 in. extension neck, providing a longer reach when cleaning.
• Equipped with a 3/8" FPT inlet, ideal for direct connection to high-pressure hoses or quick-connect fittings.
• Designed with a 22 mm rotating connector and a 14 mm output shaft, perfectly suited for industry-standard spray wands.
• Integrated safety lock system prevents accidental activation of the trigger.
• Backed by a 1 year replacement warranty.

Specifications

Pressure Rating: 3700 max PSI @ 8 GPM

Temperature Rating: 140°F

Inlet Fitting: 3/8 in. Female

Outlet Fitting: 22 mm x 1.5 mm. Male

Dimensions:

Length: 18 in.

Height: 7 in.

Depth: 3 in.
