102482-03 Ignition Transformer France 5 SAY Series Ignition Kit 29VA

In stock
Part Number
102482-03
$48.90
Part Number: 102482-03
Compatible Brands: Desa
Shipping Weight: 2 Lbs

The 102482-03 was the France 5 SAY Ignition Transformer. This ignition transformer was used in portable forced air heaters made by Desa International. This kit has since been replaced by the 102482-04 ignition transformer, which is an aftermarket equivalent to the 102482-03.


1

This new version ignition transformer module for the 102482-03 has the following specifications:

Gas Ignition Power Supply:

Primary: 120 Volts / 60 hertz 35VA

Secondary: 8.25KV, 16.5kVP 24mA

Main Lead: 24 Inches

Power Leads: 16 Inches



Service Note: Previous version FRANCE 5SAY has the following specifications:

Gas Ignition Power Supply:

  • Primary: 120 Volts / 60 hertz 29VA
  • Secondary:6Kv .15kVP 30mA
  • Spark Plug lead is 28 Inches.
  • Secondary Power Lead red and White 16 Inches
Ignition transformer
