10002389 Pilot Assembly Natural Gas with Interrupter Circuit Thermocouple

The 10002389 Pilot Assembly is a top-mount natural gas pilot with a top-convertible 3-flame directional hood and interrupter circuit thermocouple.

This Natural Gas pilot assembly is an OEM replacement HHT Home and Hearth Technologies component used on Vermont Castings, Majestic, Monessen, and other fireplaces, stoves, and other hearth products.

Propane pilot assembly 10002389 includes a 600 mm thermocouple, thermo-generator, and injector orifice.
The 1/8" diameter pilot tube helps to manage the speed, pressure, and flow of the gas.

Features of the 10002390 Propane Pilot

• Includes multidirectional three-way flame hood
• Ignition is provided by a target-style electrode
• Thermocouple includes 150 mm leads
• Electrode wire is rated for operation to temperatures up to 482°F (250°C)
• Includes aluminum pilot tube with valve hardware
• For use with vented propane gas appliances only

Specifications of the 10002390 Propane Pilot

• Pilot Bracket Series: 652
• Pilot Hood Type: Three-Way Flame Hood
• Pilot Fuel Type: Natural Gas (NG)
• Fixed Injector Orifice Size: OEM Standard
• Thermocouple Length: 600 mm with interrupter circuit.
• Thermo-Generator Lead Wire Length: 23 in.
• Electrode Cable Length: 600 mm.
• Pilot Tube Diameter: 1/8 in.
• Pilot Tube Length: 24 in.

Do not attempt to use the 10002389 as-is with any fuel type other than natural gas. This can be a risk to the pilot assembly and other fireplace components.

The 10002389 comes configured for use with natural gas only.
