0885007 Proflame 885 Series Electronic LPG Gas Valve with Stepper Motor

The 0885007 is an SIT Proflame liquid propane gas valve that is part of the Proflame 885 series of SIT gas valves. This electronic gas valve is designed for use with liquid propane heating appliances that have an electronic IPI.

This 885 Proflame series gas valve features an automatic Hi/Lo adjustable stepper motor.

Specifications for the 0.885.007 Gas Valve

Gas Type: Liquid Propane Gas

Max. Capacity: 97,000 BTU/Hr. @ 1 in. w.c pressure drop

Pressure Setting Range: 10 in. w.c to 6.4 in. w.c

Maximum Inlet Pressure: 1/2 PSIG

Ambient Operating Temperature: 32° - 175°F

Valve Connection for Pilot: 7/16 UNS x 1/4 in.

Inlet Valve: 3/8 in. NPT

Outlet Valve: 3/8 in. NPT

Electrical Information

Voltage: 5.25 V DC

Amps: 0.0145 A

Valve Coil Resistance: 362 Ω ± 10% @ 68°F

Motor Coil Resistance: 24 Ω ± 10% @ 68°F
