ST-6 Flow Switch Suttner

The ST-6 Flow Switch is used on multiple brands of portable and stationary hot and cold water pressure washers.

A flow switch is a valuable device that opens and closes electrical continuity to shut off or start machines depending on the flow -or lack of flow- of water in a high-pressure system.
This device uses a spring-assisted floating magnet to connect brass reeds to open and close the electrical circuit.

The Suttner 200006703 ST-6 flow switch can be mounted vertically or horizontally and placed further downstream in a water system than traditional vacuum switches. It can be used up to a pressure of 5070 PSI and a max flow rate of 8 GPM.

Specifications:

• Maximum Pressure Range: 350 Bar - 5070 PSI
• Maximum Temperature: 80° Celsius - 176° Fahrenheit
• Maximum Flow Rate: 1 GPM
• Minimum Flow Rate: 8 GPM
• Inlet: 3/8" MPT
• Outlet: 3/8" MPT
• 47 Inch Cord
